Ceilings
600 × 600 metal and acoustic ceiling tiles, lay-in and clip-in
GYPTECH metal ceiling tiles give a demountable ceiling: a plain or perforated metal face with an acoustic backing, carried on an exposed grid or a concealed spring carrier. Any tile can be opened, so the services above stay reachable without cutting or making good.
- Saudi Aramco registered vendor — vendor code 10064288
- Supply and install, one contract
- Local stock in Al Khobar
Project details
The more detail you give us, the sharper the price.
Request received
Thank you. A GYPTECH engineer will review your scope and come back to you.
Specification
Ceiling tiles
- Standard module
- 600 × 600 mm
- Other modules
- 300 × 300, 300 × 600, 300 × 1200, 300 × 1800, 600 × 1200, 600 × 1800 and 1200 × 1200 mm; custom formats on request
- Mounting
- Lay-in on an exposed T-grid, 15 or 24 mm face (T15 / T24); clip-in on a concealed T- or A-spring carrier, released with a key tool; hook-in specified per project
- Tile material
- Aluminium 3000-series to ASTM B209M, 0.5–0.8 mm, or hot-dip galvanized steel to ASTM A653, Z120/G40 zinc coating as standard, 0.5–0.7 mm
- Face
- Plain or perforated; perforation pattern, hole diameter and open area specified per project
- Acoustic backing
- Heat-bonded nonwoven acoustic fleece on the rear face; optional 25 mm mineral wool pad to ASTM C612, density confirmed per project
- Edge
- Bevelled or square, with a range of drop appearances
- Coating
- Polyester 5 µm back / 20 µm face, or polyester powder 70–80 µm; PVDF or polyamide on request; colour confirmed per project
- Suspension
- M6 threaded rod with nut and washer, or hanging wire with butterfly clips; perimeter edge trim in the tile material and finish; grid components specified to ASTM C635
How we work
- 01Send your drawings or BOQ
- 02We return a system proposal with quantities
- 03Supply
- 04Installation by our own crews
- 05Snag list and sign-off
Sectors we supply
- Offices
- Education
- Healthcare
- Hospitality
- Mosques
- Industrial
Frequently asked questions
Lay-in or clip-in — what is the difference?
A lay-in tile rests in an exposed T-grid (15 or 24 mm face) and lifts out by hand. A clip-in tile clips onto a concealed T- or A-spring carrier for a flush ceiling with no visible grid, and is released with a key tool. Hook-in mounting is also offered, specified per project.
What makes a metal tile acoustic?
The perforated face together with the backing behind it: a heat-bonded acoustic fleece on the rear face and, where specified, a 25 mm mineral wool pad. The perforation pattern, open area and backing are chosen per project.
Can you match an existing grid?
Lay-in tiles are made for T15 and T24 exposed grids. Send us the existing grid type and module and we confirm the tile format, edge and carrier at submittal.
Do you supply only, or supply and install?
Both, under one contract if you need it: tiles, grid or carrier, perimeter trims, hangers and fixings, supplied with installation. Light fittings, diffusers and sprinklers are coordinated into the grid module with the MEP design.
What drawings do you need to price?
A reflected ceiling plan or a BOQ, with the ceiling height, the module and mounting type you want, plain or perforated face, and the light and diffuser positions. We confirm the module and carrier type in our proposal.
Ready to price your project?
Send your drawings or BOQ and we'll return a system proposal with quantities.
